Lot (50) kobicon 16PJ031 switched power jacks 5.5X2.1
Only THREE lots of FIFTY remaining!
We just bought out a long time Phoenix surplus electronics distributor. All of these parts are absolutely "as new", most are aerospace quality, and most are leading traditional American brands. The bulk of the items are unused production overstock. Offered items are not ROHS compatible or compliant.
Offered here are lots of fifty premium grade DC power jacks that include single disconnect switches. Switching is highly useful for automatic power changeover or charger current limiting.
Many of these appear to be Kobiconn part number 16PJ031. These can also be direct soldered for thru-hole pc mount. Alternately, they can be superglued in place and direct wired. Apparently intended for the popular 5.5 mm outside diameter, 2.1 mm inside diameter dc power plugs widely used on wall warts.
Noryl black plastic with silver plated brass contacts. Inner pin is 7.5 mm long.
Power jack approximates a 3/8 inch cube. Contacts rated 1 amp.
Some units appear to be a competitive and apparently compatible product of DP-42F TP/4340002 by uElect. The exact shape of the pins are slightly different. Both types should be fully interchangeable. Both have identical footprint and accept the same plug. You normally will receive all of one type per lot. And, if possible, per order.
Guaranteed usable. Power jacks received in "as new" and apparently unused condition in individual poly bags. Switches may include minor storage cosmetics. Current production.
You can click here to reach the Full specs, switch schematics, and dimensional drawings.
