New logixpro plc simulator , rslogix 500, training,
LogixPro - THIS IS THE BEST PLC TRAINING SOFTWARE ON THE MARKET TODAY !! IT IS BASED ON ALLEN BRADLEY RSLOGIX 500.
I HAVE USED THIS SOFTWARE TO TRAIN FOREMEN, JOURNEYMEN, AND APPRENTICES IN CLASSES AND SEMINARS.
I HAVE INCLUDED 30 WORKING SOLUTIONS.
( NOTE: THESE SOLUTIONS WILL SAVE YOU HUNDREDS OF HOURS OF PROGRAMMING, THEY ARE READY TO DOWNLOAD AND RUN, AND INCLUDE RUNG COMMENTARY WITH SYMBOL AND INSTRUCTION IDENTIFICATION)
3) SILO AUTOMATED FILLING SYSTEM
3) TRAFFIC CONTROL W/ CASCADING TON TIMERS
3) TRAFFIC CONTROL W/ WORD COMPARE INSTRUCTIONS
3) BATCH MIXING USING COUNTERS
5) DUAL COMPRESSOR INCLUDING ALTERNATING, LOAD SHARING, AND BCD CONVERSIONS
5) ADVANCED BOTTLE LINE PROGRAMS W/ BIT SHIFT INSTRUCTIONS ( MOST COMPLEX BOTTLE LINE HAS 25 RUNGS IN MAIN AND 2 SUBROUTINES )
1) MULTI FLOOR ELEVATOR PROGRAM - 7 PAGES ( 1 MAIN PROGRAM & 6 SUBROUTINES )
*) THE LOGIXPRO CD IS THE "KEY" AND MUST BE IN THE DRIVE IN-ORDER FOR THE PROGRAM TO OPERATE.
*) THE SOLUTIONS CAN BE SAVED TO YOUR DESKTOP AND OPERATED FROM THERE.
Software Simulations for Industrial Training
Programmable Process Simulations
ProSim-II Simulations is an interactive educational tool, developed to assist students in the acquisition of the programming skills used in the control of process oriented equipment and systems. Although designed primarily for use with Programmable Logic Controllers (PLCs), the flexible interface of the ProSim package readily allows it to be used with any computer programming language which supports ActiveX objects in a MS Windows environment.
Typical industrial processes such as material transfer operations using a conveyor or batch mixing tanks complete with pumps and metering are graphically displayed on the screen. The displayed processes are fully animated and when used with a PLC or PLC emulator, will respond to the signals of the PLC in the same manner that actual process equipment and sensors would respond. For example, a properly addressed PLC output can be used to start a pump on a mixing tank. Once started, visual indication of the pump's rotation and fluid flow will appear on the computer screen. In addition, a digital signal representative of fluid flow would be transferred back as an input to the PLC program.
......... And More On The Way.! ........
Industrial Applications Software (Simulations):
The ProSim-II software includes the following simulated processes:
(1) Hardware I/O and BCD Simulator/Tester/Demonstrator
* 32 switches (2x16), user selectable by type
* 32 lights (2x16), user selectable color
* 4 Hexidecimal LED displays
* 4 Binary Coded Decimal Thumbwheel Switches
(2) Motorized Garage Door simulation
* Operator Station Panel and controls
* Up, Down and Stop Push-button Station
* Run, Open, Shut Panel Indicators
* Open and Closed limit swithes
* Operator Station Panel and controls
* Conveyor with position sensors (photo switch)
* Hopper with motorized chute control
(4) Intersection Traffic Light Control Simulation
* 2-way traffic intersection system
* 2 Vehicle Sensor Grid Switches
(5) Batch Mixing system Simulation
* 2 flow meters on filler lines
* 2 level sensors (hi and low)
* 1 gas fired heater (controlled valve)
(6) (BCD) Binary Coded Decimal Simulator
* 2 Hexidecimal LED displays
* 2 Decimal/Hexidecimal Thumbwheel Switches
* User Option of Decimal or Hexidecimal Modes
* Real-time Bit Indication Status
(7) (Comp) Dual Compressor Control Simulator
* User adjustable Air-flow utilization.
* 2 Pressure Switches (adjustable setpoint and span)
* 2 Binary Coded Decimal LED displays
* 2 Binary Coded Decimal Thumbwheel Switches
(8) 4 Floor Elevator Simulator
* Car mounted Control Panel c/w switches and lamps
* Bi-directional Door Motor c/w limit switches
* Bi-directional Elevator Motor c/w shaft encoder
* 6 Wall mounted service request switches c/w built in lamps.
* 4 Wall mounted plus 1 car mounted floor indicator lamps (quad)
* Full Operator Control Panel
* Presence, Bottle Size, and Broken Bottle Detection Switches
* Scrap Divertor Gate, and Scrap Grinder
* Scrap Boxing Conveyor Line
* IBM compatible PC 486 100Mhz
* VGA color display using default small fonts
* Microsoft Windows95/98/NT/2K/XP installed
