Electroswitch 6 pole 3 pos heavy duty switch 20A 600V
Only TWO remaining of this exact style!
Electroswitch is one of the finest manufacturers of heavy duty electrical utility quality
switches and similar products. These are often hard to find and outrageously priced.
The switches are rated 2 horsepower or 20 amps at 110 vac up to an unusually
high 6 amps at 600 vac. They typically are three inches in diameter and each pole
adds 5/8 of an inch to the switch depth. The shaft is an industrial standard 1/4 inch square.
Switching action is "bridging". If there are contacts A, B, C, and D, The first
switch position connects A to B. The second connects B to C. The third
connects C to D. There are eight positions around the switch. Restraining
screws can be used to limit operation to a fewer number of positions.
These are perfect for motor controls, robotics, automation, or other
shop floor uses where a premium quality, super rugged switch is
required for direct control of motors and similar higher current loads.
Offered here is a three deck version with two contact sets
of four positions per deck. This gives an off, AB, BC, CD
switching action. That also can be configured off-on#1-on#2,
on#1-off-on#2, off-on#1-on#1 or other possibilities. The
basic normal switching action is six pole, double throw.
The shaft extends 1-3/4 inches out the front. There is a three point
front panel mount adaptor included. Knob and bezel are not included.
Presently set to three positions that bridge two separate pairs of four
contacts. Switch extends 3-1/2 nches behind panel.
You can click here to reach the Electroswitch Series 24 datasheet.
Image shown is of a typical switch in our offerings. The switch
being listed here has three decks and two independent pairs of four
bridging contact positions per deck.
Guaranteed usable. Received by us as public power company surplus.
Removed from equipment, cleaned, and checked. Condition is typicallly
"near new". May include minor cosmetics. Accessories as noted.
deck industrial heavy duty panel mount switch rated to 600 volts. 6PDT or
