Cole-parmer line-powered rate/totalizer/batch controlle
Cole-Parmer Line-Powered Rate/Totalizer/Batch Controlle
Cole Parmer 94788-50, Unit in good condition, the front cover at the time of picture had some scuffs as you can see, but have ordered a new replacement lens
Display flow rates in any engineering unitEasily scale and calibrate using a single buttonCalibration bail-out with one touchLatching and non-latching relaysAny relays programmable for rate or totalEAsy access to diagnostic menuTime base in seconds, minutes, hours, or even days!Enhanced priority batch programming
These flow rate monitor/totalizers display flow rate and total flow (resettable) in any engineering unit. Meters feature low flow cutoff and nonvolatile memory that stores settings even after power turns off. Models with totalizer can be programmed so the display alternates between flow rate and total flow. Choose from loop-powered or line-powered monitor/totalizers. Loop-powered meters are ideal for areas where line power is not available; use line-powered meters for controlling auxiliary equipment. All monitor/totalizers have sealed NEMA Type 4X front panel; housing is made from high-impact plastic and fits standard 1/8 DIN cutout. All meters include panel mounting hardware.Use these line-powered meters to display flow rate and total flow as well as to provide simple batch control. Meters feature peak hold and batch programming that allows you to change the preset batch values without entering the main menu. Easily calibrate meter by selecting internal calibration mode or by using an external signal such as a calibrator. Linearization feature lets you enter up to 11 calibration points to handle non-linear input signals. Monitor/totalizers are available in analog or frequency input. Analog input models accept 4 to 20 mA, 0 to 5 V, or 0 to 10 V signals; and provide 24 VDC @ 20 mA excitation output. Frequency input models are switch-selectable for pulse, open collector, switch closure, TTL, or square wave signals; and provide 12 VDC @ 50 mA or 24 VDC @ 20 mA excitation output. Select from models with two or four relays for on/off control of pumps, valves, or alarms. For proportional control or to send data to a recorder, order models with 4 to 20 mA output. Meters with combination of relays and 4 to 20 mA output provides the most flexibility.
Operating ambient32 to 149(0 to 65)Accuracy.05% of calibrated span countDisplay6-digit, 9/16"H LED; may be programmed to alternate between rate and total every 10 seconds|Rate: 0 to 29,999(0) with selectable extra zero|Total: 0 to 999,999Input signal1 Hz to 30 KHzOutput4 to 20 mARelays2 Relays; 2A@250VACPower115 VAC, 50/60 HzDimensions4-1/4"Wx2-5/16"Hx4-1/2"DPanel cutout3-5/8"Wx1-25/32"Hx6"
If you have questions or need additional information on an item please CONTACT US !, items are sold as it is shown in the pictures, if it is not shown in the picture then it most likely is not included. We encourage you to ask questions to clarify everything, we want you to know what your getting and feel comfortable with your purchase...
